DXT-168 High-precision Smart Magnetometer

DXT-168 High-precision Smart Magnetometer

DXT-168 high-precision smart magnetometer with high precision, high resolution, high stability is suitable for deep geological and mineral resources exploration, and was widely used in scientific research, petroleum, metallurgy, nonferrous metals, earthquake prediction, geological environment, archeology, metal detection and other fields.

Production introduction

DXT-168 high-precision smart magnetometer with high precision, high resolution, high stability is suitable for deep geological and mineral resources exploration, and was widely used in scientific research, petroleum, metallurgy, nonferrous metals, earthquake prediction, geological environment, archeology, metal detection and other fields.

Technical parameters

1. Resolution: 0.01nT

2. Sensitivity: 0.01nT

3. Accuracy: 0.05nT

4. Tuning range: 20000 nT ~ 100000 nT

5. Sampling rate: 4s~ 999s, set arbitrarily

6. Display: the data and curve of liquid crystal display

7. Built-in clock at normal temperature: 5s/month

8. Gradient tolerance: 7000 nT/M

9. Temperature drift coefficient: ≤0.001 nT/˚C

10. Data storage: 30000 sets of data in base station measurements, and the function of power-down protection

11. Data storage time at normal temperature: 10 years

12. Data output via RS-232 or USB interface output data in real-time.

13. Transmission rate: 9600 ~ 38400 baud rate

14. Software environment: data output and daily variable automatic correction system in WINDOWS environment;

15. Keyboard: 12 touch buttons;

16. Size and quantity: main engine (18cm × 27cm × 9cm) and sensor (9cm × 13cm)

17. Weigh: 2.8Kg

18. Power supply: 12V direct current power

19. Working temperature and environment: -20℃ ~ 50℃ , wind-proof and rain-proof
